Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion

Brand Name : BRANDO

Model Number : DNC

Certification : CE, ISO

Place of Origin : Ningbo, China

MOQ : 1 pc

Price : Negotiation

Payment Terms : L/C, T/T, PayPal, Western Union, MoneyGram

Supply Ability : 100000 pcs per month

Delivery Time : 4-7 work days

Packaging Details : Inner Box, Carton, Pallet

Product Series : Piston Rod Cylinder

Bore Size (mm) : 32, 40, 50, 63, 80, 100, 125

Standard Stroke (mm) : 25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300, 350, 400, 450, 500, 600, 700, 800, 900, 1000

Acting Type : Double Acting

Operating Pressure Range : 0.15 to 1.0 MPa

Proof Pressure : 1.5 MPa

Contact Now

Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion

A pneumatic cylinder is a type of appliance that makes the use of power that is generated from compacted gas in order to form a force in interchanging linear motion. A pneumatic cylinder may also be referred to as an air cylinder, as the term pneuma, means air. Very similar to hydraulic cylinders, a force is applied into the piston, which pushes it to the desired direction. The piston that is part of a pneumatic cylinder is a disc or a cylinder. The force that is created is transported by the piston rod to the object that requires moving. A minority of engineers prefer this device due to its cleanness, quietness, and minimum space for storing fluids.


Specifications of DNC Series Pneumatic Cylinder:

Bore Size (mm) 32 40 50 63 80 100 125
Acting Type Double Acting
Fluid Air (to be filtered by 40μm filter element)
Operating Pressure Range 0.15 to 1.0 MPa (1.5 to 10.0 bar) (22 to 145 psi)
Proof Pressure 1.5 MPa (15 bar) (215 psi)
Temprature (℃) -20 to +80
Speed Range (mm/s) 30 to 800
Cushion Type Variable cushion
Port Size 1/8'' 1/4'' 3/8'' 1/2''


Stroke of DNC Series Pneumatic Cylinder:

Bore Size (mm) Standard Stroke (mm) Max. Std Stroke Max. Stroke
32

25, 50, 75, 80, 100, 125, 150, 160, 175,

200, 250, 300, 350, 400, 450, 500

 1000 1800
40

25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250,

300, 350, 400, 450, 500, 600, 700, 800

 1200 1800
50

25, 50, 75, 80, 100, 125, 150, 160, 175, 200, 250, 300,

350, 400, 450, 500, 600, 700, 800, 900, 1000

 1200 1800
63 1500 1800
80 1500 1800
100 1500 1800
125 1500 1800


Ordering Code of DNC Series Pneumatic Cylinder:


Festo Type DNC-50-50-PPV-A Pneumatic Cylinder Adjustable Cushion

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing

Welcome to your any question and inquiry!
