2V025-08 1/4'' NPT 2/2 Way Direct Acting Pneumatic Solenoid Valve
Description of 2V025-08 Solenoid Valve:
1.The strength of the aluminum alloy valve body is large. The valve body is made of new aluminum alloy material, which has strong pressure resistance,good corrosion resistance and fast heat dissipation.
2.High quality sealing ring. High quality seals for durability and longer life
3.High frequency sub-head. Made of high-quality conductor material with 6 times in 1 second high intensity and high frequency response for smoother operation
4.The coil is easy to disassemble. Removable core nut, coil damage can be replaced at any time
5.High quality electronic components. The copper coil can work hard for a long time, and the wiring operation is simple.
6.Used for controlling pilots or diaphragms of larger valves or small cylinders or any pressure system that is alternatively pressurized and exhausted.
Product Video of 2V025-08 Solenoid Valve:
Main dimension of 2V025-08 Pneumatic Solenoid Valve:
Technical parameters of 2V Series Pneumatic Solenoid Valve:
| Model No | 2V025-06 | 2V025-08 |
| Fluids | Air. Water. Oil |
| Action | Direct acting |
| Type | Normally Closed (NC) |
| Orifice size(φmm) | 2.5 | 2.5 |
| Cv value | 0.23 | 0.25 |
| Port size | 1/8" | 1/4" |
| Viscosity limit | Under 20Cst |
| Pressure range | 0~1.0MPa (0~145psi) |
| Proof pressure | 1.5MPa (215psi) |
| Material body | Anodized Aluminum |
| Seal material | NBR |
| Min. activating time sec | 0.05 sec and below |
More Pneumatic Solenoid Valves for you to choose:
Brando offers multiple port and position configurations. Most air control valves are available with 220VAC, 110VAC, 24VDC or 12VDC solenoid coils. Select from 5/2 way, 5/2 way or 3/2 way.
Brando Supply:
1. 5/2 Way Pneumatic Solenoid Valve: 4V110-06, 4V120-06, 4V210-06, 4M220-06, 4V210-08, 4V220-08, 4V310-08, 4V320-08, 4V310-10, 4V410-15, 4V420-15, 4M110-06, 4M120-06, 4M210-06, 4M220-06, 4M210-08, 4M220-08, 4M310-08, 4M320-08, 4M310-10, 4M320-10
2. 5/3 Way Pneumatic Solenoid Valve: 4V130C-06, 4V130E-06, 4V130P-06, 4V230C-06, 4V230E-06, 4V230P-06, 4V230C-08, 4V230E-08, 4V230P-08, 4V330C-08, 4V330E-08, 4V330P-08, 4V330C-10, 4V330E-10, 4V330P-10, 4V430C-15, 4V430E-15, 4V430P-15
3. 2/2 Way Pneumatic Solenoid Valve: 2V025-06, 2V025-08
