2'' C50 C52 Pulse Jet Valve Diaphragm Repair Kit For Industrial Bag Filter

2'' C50 C52 Pulse Jet Valve Diaphragm Repair Kit For Industrial Bag Filter

This diaphragm (membrane) is used for C50 pulse valve. Diaphragm material is NBR. 1 set includes 1pc big diaphragm, 1pc small diaphragm and 1pc spring. When the dust collector control board starts the cleaning cycle, it sends an electrical signal to the pulse valve, and then activates the pulse valve. Inside the pulse valve, the rubber diaphragm opens and closes to release the compressed air stored in the air header. At this time, the air enters the blowing pipe above the filter through the valve, and then enters the filter down to clean the filter bag.

Main Dimension:

Product Video:

Our Production:

Focus on your demands, Offer you best solution:

√ Contact us if some points you have doubt

√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for

√ Contact us if you are doing designing

Welcome to your any question and inquiry!

2'' C50 Diaphragm Repair Kit

C52 Diaphragm Repair Kit

Membrane For C52

2'' C50 C52 Pulse Jet Valve Diaphragm Repair Kit For Industrial Bag Filter Images
